دیتاشیت UC3825Q

مشخصات دیتاشیت

دانلود دیتاشیت UC1825, 2825, 3825	UC1825, 2825, 3825 Datasheet

Function: Step-Up, Step-Down, Step-Up/Step-Down
Packaging: Tube
Series: -
Supplier Device Package: 20-PLCC (9x9)
Serial Interfaces: -
Topology: Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Control Features: Current Limit, Enable, Frequency Control, Ramp, Soft Start
Part Status: Obsolete
Base Part Number: UC382
Synchronous Rectifier: No
Clock Sync: No
Operating Temperature: 0°C ~ 70°C (TA)
Duty Cycle (Max): 85%
Output Configuration: Positive
Manufacturer: Texas Instruments
Mounting Type: Surface Mount
Number of Outputs: 2
Output Phases: 1
Output Type: Transistor Driver
Package / Case: 20-LCC (J-Lead)
Voltage - Supply (Vcc/Vdd): 8.4V ~ 30V
Frequency - Switching: 340kHz ~ 460kHz
detail: Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 20-PLCC (9x9)
