دیتاشیت SN74HC175NSR

مشخصات دیتاشیت

دانلود دیتاشیت SN54HC175, SN74HC175	SN54HC175, SN74HC175 Datasheet

RoHS: true
Category: Logic ICs/Flip Flops
Datasheet: Texas Instruments SN74HC175NSR
Package: SO-16-208mil
Manufacturer: Texas Instruments
Series: 74HC
Type: D-Type
Package / Case: 16-SOIC (0.209", 5.30mm Width)
Current - Output High, Low: 5.2mA, 5.2mA
Number of Elements: 1
Function: Master Reset
Clock Frequency: 60MHz
Current - Quiescent (Iq): 8µA
Part Status: Active
Number of Bits per Element: 4
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C (TA)
Max Propagation Delay @ V, Max CL: 26ns @ 6V, 50pF
Input Capacitance: 3pF
Voltage - Supply: 2V ~ 6V
Packaging: Cut Tape (CT)
Base Part Number: SN74HC1
Supplier Device Package: 16-SO
Output Type: Differential
Trigger Type: Positive Edge
detail: Flip Flop 1 Element D-Type 4 Bit Positive Edge 16-SOIC (0.209", 5.30mm Width)
