دیتاشیت MC68HC705P6ACP

مشخصات دیتاشیت

دانلود دیتاشیت MC68HC705P6A	MC68HC705P6A Datasheet

Manufacturer: NXP USA Inc.
Series: HC05
Packaging: Tube
Part Status: Obsolete
Core Processor: HC05
Core Size: 8-Bit
Speed: 2.1MHz
Connectivity: SIO
Peripherals: POR, WDT
Number of I/O: 21
Program Memory Size: 4.5KB (4.5K x 8)
Program Memory Type: OTP
EEPROM Size: -
RAM Size: 176 x 8
Voltage - Supply (Vcc/Vdd): 3V ~ 5.5V
Data Converters: A/D 4x8b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Through Hole
Package / Case: 28-DIP (0.600", 15.24mm)
Supplier Device Package: 28-PDIP
Base Part Number: MC68
detail: HC05 HC05 Microcontroller IC 8-Bit 2.1MHz 4.5KB (4.5K x 8) OTP 28-PDIP
