دیتاشیت DG441DY

DG441-42

مشخصات دیتاشیت

نام دیتاشیت DG441-42
حجم فایل 129.463 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت DG441-42

DG441-42 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 1:1
  • Part Status: Obsolete
  • Charge Injection: 5pC
  • -3db Bandwidth: -
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): ±4.5V ~ 20V
  • Supplier Device Package: 16-SO
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Switch Time (Ton, Toff) (Max): 250ns, 120ns
  • Packaging: Tube
  • Channel-to-Channel Matching (ΔRon): 4Ohm (Max)
  • Voltage - Supply, Single (V+): 10V ~ 30V
  • Channel Capacitance (CS(off), CD(off)): 4pF, 4pF
  • Switch Circuit: SPST - NC
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -100dB @ 1MHz
  • Number of Circuits: 4
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 500pA
  • Base Part Number: DG441
  • On-State Resistance (Max): 85Ohm
