دیتاشیت MC33063ADR2G

مشخصات دیتاشیت

دانلود دیتاشیت MC3x063A, SC3x063A, NCV33063A	MC3x063A, SC3x063A, NCV33063A Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType;Step-down type
Topology: Step-down;Boost
Datasheet: onsemi MC33063ADR2G
Output Type: Adjustable
Input Voltage: 3V~40V
Output Voltage: 1.25V~40V
Number of Outputs: 1
Switching Frequency: 33kHz
Output Current (Max): 1.5A
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: NO
Package: SOP-8
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive or Negative
Voltage - Input (Min): 3V
Voltage - Input (Max): 40V
Voltage - Output (Min/Fixed): 1.25V
Voltage - Output (Max): 40V (Switch)
Current - Output: 1.5A (Switch)
Frequency - Switching: 33kHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 8-SOIC
Base Part Number: MC33063
detail: Buck, Boost Switching Regulator IC Positive or Negative Adjustable 1.25V 1 Output 1.5A (Switch) 8-SOIC (0.154", 3.90mm Width)
