دیتاشیت MOC3063SR2M

MOC3061-63M, 3162M-63M

مشخصات دیتاشیت

نام دیتاشیت MOC3061-63M, 3162M-63M
حجم فایل 461.719 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت MOC3061-63M, 3162M-63M

MOC3061-63M, 3162M-63M Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Type: Triac
  • Zero Crossing Circuit: Yes
  • Number of Channels: 1
  • Voltage - Isolation: 4170Vrms
  • Voltage - Off State: 600V
  • Static dV/dt (Min): 600V/µs
  • Current - LED Trigger (Ift) (Max): 5mA
  • Current - Hold (Ih): 500µA (Typ)
  • Turn On Time: -
  • Voltage - Forward (Vf) (Typ): 1.3V
  • Current - DC Forward (If) (Max): 60mA
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 6-SMD, Gull Wing
  • Supplier Device Package: 6-SMD
  • Approval Agency: UL
  • Base Part Number: MOC306
  • detail: Optoisolator Triac Output 4170Vrms 1 Channel 6-SMD
