دیتاشیت ACPL-C87B-500E

ACPL-C87B-500E

مشخصات دیتاشیت

نام دیتاشیت ACPL-C87B-500E
حجم فایل 131.925 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت ACPL-C87B-500E

ACPL-C87B-500E Datasheet

مشخصات

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Digital Isolators
  • Datasheet: Broadcom/AVAGO ACPL-C87B-500E
  • Applications: -
  • Isolation Technology: -
  • Voltage Isolation or Not: -
  • Package: SOP-8-6.8mm
  • Manufacturer: Broadcom/AVAGO
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Amplifier Type: Isolation
  • Number of Circuits: 1
  • Output Type: Differential
  • Slew Rate: -
  • -3db Bandwidth: 100kHz
  • Current - Input Bias: 1.5nA
  • Voltage - Input Offset: 300µV
  • Current - Supply: 10.5mA
  • Current - Output / Channel: 30mA
  • Voltage - Supply, Single/Dual (±): 3V ~ 5.5V
  • Operating Temperature: -40°C ~ 105°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.268", 6.81mm Width)
  • Supplier Device Package: 8-SO Stretched
  • Base Part Number: ACPL-C87
  • detail: Isolation Amplifier 1 Circuit Differential 8-SO Stretched
