- دیتاشیت MOC3062M
MOC3062M دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MOC3062M |
|---|---|
| حجم فایل | 70.222 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت MOC3062M |
دانلود دیتاشیت |
|---|
سایر مستندات
MOC3061-63M, 3162M-63M 14 pages
MOC3063SM 6 pages
مشخصات فنی
- RoHS: true
- Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Thyristor Signal Output
- SCR Type: Two-way thyristor
- Datasheet: onsemi MOC3062M
- Forward Current: 60mA
- Forward Voltage: 1.3V
- Number of Outputs: 1
- Operating Temperature: -40°C~+85°C
- Zero Crossing Circuit: Yes
- Isolation Voltage(rms): 4170V
- Peak Off-state Voltage(Vdrm): 600V
- RMS On-State Current(It(rms)): -
- Package: DIP-6
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Type: Triac
- Number of Channels: 1
- Voltage - Isolation: 4170Vrms
- Voltage - Off State: 600V
- Static dV/dt (Min): 600V/µs
- Current - LED Trigger (Ift) (Max): 10mA
- Current - Hold (Ih): 500µA (Typ)
- Turn On Time: -
- Voltage - Forward (Vf) (Typ): 1.3V
- Current - DC Forward (If) (Max): 60mA
- Mounting Type: Through Hole
- Package / Case: 6-DIP (0.300", 7.62mm)
- Supplier Device Package: 6-DIP
- Approval Agency: UL
- Base Part Number: MOC306
- detail: Optoisolator Triac Output 4170Vrms 1 Channel 6-DIP
