دیتاشیت LMV331SQ3T2G
مشخصات دیتاشیت
| نام دیتاشیت | LMV331,39,93, NCV331 |
|---|---|
| حجم فایل | 860.103 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LMV331,39,93, NCV331 |
LMV331,39,93, NCV331 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: onsemi LMV331SQ3T2G
- Output Type: Open Drain
- Supply Voltage: 2.7V~5V
- Number of Elements: -
- Operating Temperature: -
- Input Bias Current (Ib): 0.001uA
- Input Offset Voltage (Vos): 9mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): -
- Package: SC-88A
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: General Purpose
- Voltage - Supply, Single/Dual (±): 2.7V ~ 5V
- Voltage - Input Offset (Max): 9mV @ 5V
- Current - Input Bias (Max): 0.001µA @ 5V
- Current - Output (Typ): 84mA @ 5V
- Current - Quiescent (Max): 150µA
- CMRR, PSRR (Typ): -
- Propagation Delay (Max): 1.5µs
- Hysteresis: -
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Mounting Type: Surface Mount
- Supplier Device Package: SC-88A (SC-70-5/SOT-353)
- Base Part Number: LMV33
- detail: Comparator General Purpose Open Drain SC-88A (SC-70-5/SOT-353)
