دیتاشیت MMBTA06

MMBTA06

مشخصات دیتاشیت

نام دیتاشیت MMBTA06
حجم فایل 54.234 کیلوبایت
نوع فایل pdf
تعداد صفحات 2

دانلود دیتاشیت MMBTA06

MMBTA06 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
  • Datasheet: UMW(Youtai Semiconductor Co., Ltd.) MMBTA06
  • Transistor Type: NPN
  • Operating Temperature: +150°C@(Tj)
  • Collector Current (Ic): 500mA
  • Power Dissipation (Pd): 300mW
  • Transition Frequency (fT): 100MHz
  • DC Current Gain (hFE@Ic,Vce): 100@10mA,1V
  • Collector Cut-Off Current (Icbo): 100nA
  • Collector-Emitter Breakdown Voltage (Vceo): 80V
  • Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 250mV@100mA,10mA
  • Package: SOT-23-3
  • Manufacturer: UMW(Youtai Semiconductor Co., Ltd.)
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Current - Collector (Ic) (Max): 500mA
  • Voltage - Collector Emitter Breakdown (Max): 80V
  • Vce Saturation (Max) @ Ib, Ic: 250mV @ 10mA, 100mA
  • Current - Collector Cutoff (Max): 100nA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 100mA, 1V
  • Power - Max: 350mW
  • Frequency - Transition: 100MHz
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23-3
  • Base Part Number: MMBTA06
