دیتاشیت 1N4305
مشخصات دیتاشیت
| نام دیتاشیت |
1N4305
|
| حجم فایل |
109.917
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
1
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
75V
-
Current - Average Rectified (Io):
300mA
-
Voltage - Forward (Vf) (Max) @ If:
850mV @ 10mA
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
4ns
-
Current - Reverse Leakage @ Vr:
100nA @ 50V
-
Capacitance @ Vr, F:
2pF @ 0V, 1MHz
-
Mounting Type:
Through Hole
-
Package / Case:
DO-204AH, DO-35, Axial
-
Supplier Device Package:
DO-35
-
Operating Temperature - Junction:
175°C (Max)
-
Base Part Number:
1N4305
-
detail:
Diode Standard 75V 300mA Through Hole DO-35
