دیتاشیت TL594CD
مشخصات دیتاشیت
| نام دیتاشیت |
TL594CD
|
| حجم فایل |
99.314
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
37
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Controllers
-
Datasheet:
Texas Instruments TL594CD
-
Package:
SOIC-16
-
Manufacturer:
Texas Instruments
-
Series:
SWITCHMODE™
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Output Type:
Transistor Driver
-
Function:
Step-Down, Step-Up/Step-Down
-
Output Configuration:
Positive
-
Topology:
Buck, Push-Pull
-
Number of Outputs:
2
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
7V ~ 40V
-
Frequency - Switching:
300kHz
-
Duty Cycle (Max):
96%
-
Synchronous Rectifier:
Yes
-
Clock Sync:
No
-
Serial Interfaces:
-
-
Control Features:
Dead Time Control, Frequency Control
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
16-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
16-SOIC
-
Base Part Number:
TL594
