دیتاشیت NCP1402SN50T1G
مشخصات دیتاشیت
| نام دیتاشیت |
NCP1402
|
| حجم فایل |
176.679
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
18
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
onsemi NCP1402SN50T1G
-
Input Voltage:
0.8V~5V
-
Output Voltage:
5V
-
Number of Outputs:
1
-
Switching Frequency:
200kHz
-
Output Current (Max):
130mA
-
Synchronous Rectification:
NO
-
Package:
SOT-23-5
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Voltage - Input (Min):
0.8V
-
Voltage - Input (Max):
5V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Current - Output:
130mA (Switch)
-
Frequency - Switching:
Up to 200kHz
-
Synchronous Rectifier:
No
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-23-5 Thin, TSOT-23-5
-
Supplier Device Package:
5-TSOP
-
Base Part Number:
NCP1402
-
detail:
Boost Switching Regulator IC Positive Fixed 5V 1 Output 130mA (Switch) SOT-23-5 Thin, TSOT-23-5
