دیتاشیت TPS62142RGTT
مشخصات دیتاشیت
| نام دیتاشیت | TPS6214x Family |
|---|---|
| حجم فایل | 2206.869 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 41 |
دانلود دیتاشیت TPS6214x Family |
TPS6214x Family Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS62142RGTT
- Output Type: Fixed
- Input Voltage: 3V~17V
- Output Voltage: 3.3V
- Number of Outputs: 1
- Switching Frequency: 2.5MHz
- Output Current (Max): 2A
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: QFN-16-EP(3x3)
- Manufacturer: Texas Instruments
- Frequency - Switching: 2.5MHz
- Package / Case: 16-VFQFN Exposed Pad
- Supplier Device Package: 16-QFN (3x3)
- Voltage - Output (Min/Fixed): 3.3V
- Current - Output: 2A
- Output Configuration: Positive
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Output (Max): -
- Series: DCS-Control™
- Mounting Type: Surface Mount
- Voltage - Input (Max): 17V
- Base Part Number: TPS621
- Voltage - Input (Min): 3V
- Synchronous Rectifier: Yes
- detail: Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 2A 16-VFQFN Exposed Pad
