دیتاشیت TPS63030DSKT
مشخصات دیتاشیت
| نام دیتاشیت |
TPS63030,31
|
| حجم فایل |
2547.526
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
27
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Step-down-Boost
-
Datasheet:
Texas Instruments TPS63030DSKT
-
Output Current:
900mA
-
Switching Frequency:
2.4MHz
-
Operating Temperature:
-40°C~+85°C@(Ta)
-
Package:
SON-10-EP(2.5x2.5)
-
Manufacturer:
Texas Instruments
-
Frequency - Switching:
2.4MHz
-
Number of Outputs:
1
-
Package / Case:
10-WFDFN Exposed Pad
-
Supplier Device Package:
10-SON (2.5x2.5)
-
Voltage - Output (Min/Fixed):
1.2V
-
Current - Output:
900mA (Switch)
-
Output Configuration:
Positive
-
Packaging:
Cut Tape (CT)
-
Function:
Step-Up/Step-Down
-
Part Status:
Active
-
Voltage - Output (Max):
5.5V
-
Series:
-
-
Mounting Type:
Surface Mount
-
Voltage - Input (Max):
5.5V
-
Output Type:
Adjustable
-
Base Part Number:
TPS630
-
Voltage - Input (Min):
1.8V
-
Synchronous Rectifier:
Yes
-
detail:
Buck-Boost Switching Regulator IC Positive Adjustable 1.2V 1 Output 900mA (Switch) 10-WFDFN Exposed Pad
