دیتاشیت TPS54310PWPR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS54310
|
| حجم فایل |
1384.65
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
28
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
-
-
Datasheet:
Texas Instruments TPS54310PWPR
-
Input Voltage:
-
-
Number of Outputs:
-
-
Switching Frequency:
-
-
Output Current (Max):
-
-
Synchronous Rectification:
-
-
Package:
TSSOP-20-EP
-
Manufacturer:
Texas Instruments
-
Frequency - Switching:
350kHz, 550kHz
-
Package / Case:
20-PowerTSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
20-HTSSOP
-
Voltage - Output (Min/Fixed):
0.891V
-
Current - Output:
3A
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Output Configuration:
Positive
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Output (Max):
3.3V
-
Series:
SWIFT™
-
Mounting Type:
Surface Mount
-
Voltage - Input (Max):
6V
-
Output Type:
Adjustable
-
Base Part Number:
TPS543
-
Voltage - Input (Min):
3V
-
Synchronous Rectifier:
Yes
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.891V 1 Output 3A 20-PowerTSSOP (0.173", 4.40mm Width)
