دیتاشیت LM319DT
مشخصات دیتاشیت
| نام دیتاشیت |
LM119,219,319
|
| حجم فایل |
995.822
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
STMicroelectronics LM319DT
-
Output Type:
Push Pull
-
Supply Current:
12.5mA
-
Supply Voltage:
5V~30V;2.5V~15V
-
Number of Elements:
2
-
Operating Temperature:
0°C~+70°C
-
Input Bias Current (Ib):
1uA
-
Input Offset Voltage (Vos):
8mV
-
Input Hysteresis Voltage (Vhys):
-
-
Common Mode Rejection Ratio (CMRR):
70dB
-
Package:
SOP-14
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
General Purpose
-
Voltage - Supply, Single/Dual (±):
5V ~ 30V, ±2.5V ~ 15V
-
Voltage - Input Offset (Max):
8mV @ ±15V
-
Current - Input Bias (Max):
1µA @ ±15V
-
Current - Output (Typ):
-
-
Current - Quiescent (Max):
12.5mA
-
CMRR, PSRR (Typ):
-
-
Propagation Delay (Max):
-
-
Hysteresis:
-
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
14-SO
-
Base Part Number:
LM319
-
detail:
Comparator General Purpose Open-Collector, Open-Emitter, TTL 14-SO
