دیتاشیت TPS70251PWP
مشخصات دیتاشیت
| نام دیتاشیت | TPS70245/48/51/58/02 |
|---|---|
| حجم فایل | 1322.76 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 37 |
دانلود دیتاشیت TPS70245/48/51/58/02 |
TPS70245/48/51/58/02 Datasheet |
|---|
مشخصات
- Mounting Type: Surface Mount
- Current - Supply (Max): 230µA
- Control Features: Enable, Power Good, Reset, Sequencing
- Packaging: Tube
- Voltage - Output (Max): -
- Voltage - Output (Min/Fixed): 3.3V, 1.8V
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- Output Type: Fixed
- Supplier Device Package: 20-HTSSOP
- Operating Temperature: -40°C ~ 125°C
- Current - Quiescent (Iq): 190µA
- Part Status: Active
- Current - Output: 500mA, 250mA
- Series: -
- Number of Regulators: 2
- PSRR: 60dB (1KHz), 50dB (1kHz)
- Base Part Number: TPS702
- Voltage Dropout (Max): 0.28V @ 500mA, -
- Package / Case: 20-PowerTSSOP (0.173", 4.40mm Width)
- Manufacturer: Texas Instruments
- Output Configuration: Positive
- Voltage - Input (Max): 6V
- detail: Linear Voltage Regulator IC 2 Output 500mA, 250mA 20-HTSSOP
