دیتاشیت SN74HC139N

SN54HC139, SN74HC139

مشخصات دیتاشیت

نام دیتاشیت SN54HC139, SN74HC139
حجم فایل 1242.346 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت SN54HC139, SN74HC139

SN54HC139, SN74HC139 Datasheet

مشخصات

  • RoHS: true
  • Type: Decoder/Demultiplexers
  • Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
  • Datasheet: Texas Instruments SN74HC139N
  • Sink Current: 5.2mA
  • Source Current: 5.2mA
  • Supply Voltage: 2V~6V
  • Operating temperature: -40°C~+85°C
  • Voltage Supply Source: Single supply
  • Package: DIP-16
  • Manufacturer: Texas Instruments
  • Independent Circuits: 2
  • Voltage - Supply: 2V ~ 6V
  • Circuit: 1 x 2:4
  • Mounting Type: Through Hole
  • Packaging: Tube
  • Package / Case: 16-DIP (0.300", 7.62mm)
  • Part Status: Active
  • Current - Output High, Low: 5.2mA, 5.2mA
  • Series: 74HC
  • Supplier Device Package: 16-PDIP
  • Base Part Number: SN74HC1
  • detail: Decoder/Demultiplexer 1 x 2:4 16-PDIP
