دیتاشیت SN74HC273N

مشخصات دیتاشیت

دانلود دیتاشیت SN54HC273, SN74HC273	SN54HC273, SN74HC273 Datasheet

Number of Elements: 1
Trigger Type: Positive Edge
Manufacturer: Texas Instruments
Voltage - Supply: 2V ~ 6V
Series: 74HC
Operating Temperature: -40°C ~ 85°C (TA)
Package / Case: 20-DIP (0.300", 7.62mm)
Function: Master Reset
Packaging: Tube
Type: D-Type
Supplier Device Package: 20-PDIP
Clock Frequency: 60MHz
Number of Bits per Element: 8
Current - Output High, Low: 5.2mA, 5.2mA
Part Status: Active
Output Type: Non-Inverted
Base Part Number: SN74HC2
Input Capacitance: 3pF
Mounting Type: Through Hole
Current - Quiescent (Iq): 8µA
Max Propagation Delay @ V, Max CL: 27ns @ 6V, 50pF
detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-DIP (0.300", 7.62mm)
