- دیتاشیت CD4063BE
CD4063BE دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | CD4063BE |
|---|---|
| حجم فایل | 95.321 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 18 |
دانلود دیتاشیت CD4063BE |
دانلود دیتاشیت |
|---|
سایر مستندات
CD4063B Types 14 pages
CD4063BE 14 pages
مشخصات فنی
- RoHS: true
- Output: Active High
- Category: Logic ICs/Digital Comparators
- Datasheet: Texas Instruments CD4063BE
- Sink Current: 4.2mA
- Source Current: 4.2mA
- Supply Voltage: 3V~18V
- Output Function: AB
- Quiescent Current: 100uA
- Number of Channels: 4
- Operating Temperature: -55°C~+125°C
- Maximum Propagation Delay: 350ns@15V,50pF
- Package: PDIP-16
- Manufacturer: Texas Instruments
- Voltage - Supply: 3V ~ 18V
- Package / Case: 16-DIP (0.300", 7.62mm)
- Packaging: Tube
- Type: Magnitude Comparator
- Base Part Number: CD4063
- Part Status: Active
- Current - Output High, Low: 4.2mA, 4.2mA
- Series: 4000B
- Number of Bits: 4
- Supplier Device Package: 16-PDIP
- Mounting Type: Through Hole
- Current - Quiescent (Iq): 100µA
- Max Propagation Delay @ V, Max CL: 350ns @ 15V, 50pF
- detail: Magnitude Comparator Bit Active High Output AB 16-PDIP
