دیتاشیت TLC372CP
مشخصات دیتاشیت
| نام دیتاشیت | TLC372 Datasheet |
|---|---|
| حجم فایل | 1615.498 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 29 |
دانلود دیتاشیت TLC372 Datasheet |
TLC372 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Texas Instruments TLC372CP
- Output Type: -
- Supply Current: 400uA
- Supply Voltage: 3V~16V;1.5V~8V
- Number of Elements: 2
- Operating Temperature: 0°C~+70°C
- Input Bias Current (Ib): 5pA
- Input Offset Voltage (Vos): 5mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): 86.02dB
- Package: DIP-8
- Manufacturer: Texas Instruments
- Package / Case: 8-DIP (0.300", 7.62mm)
- Propagation Delay (Max): -
- Current - Quiescent (Max): 400µA
- Voltage - Input Offset (Max): 5mV @ 5V
- Part Status: Active
- Current - Output (Typ): 20mA
- Current - Input Bias (Max): 5pA @ 5V
- Packaging: Tube
- Type: Differential
- CMRR, PSRR (Typ): -
- Voltage - Supply, Single/Dual (±): 3V ~ 16V, ±1.5V ~ 8V
- Series: LinCMOS™
- Base Part Number: TLC372
- Supplier Device Package: 8-PDIP
- Mounting Type: Through Hole
- Hysteresis: -
- detail: Comparator Differential CMOS, MOS, Open-Drain, TTL 8-PDIP
