دیتاشیت BTA16-800CWRG
مشخصات دیتاشیت
| نام دیتاشیت | BT(A,B)16, T16xx |
|---|---|
| حجم فایل | 232.184 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 18 |
دانلود دیتاشیت BT(A,B)16, T16xx |
BT(A,B)16, T16xx Datasheet |
|---|
مشخصات
- Manufacturer: STMicroelectronics
- Series: Snubberless™
- Packaging: Tube
- Part Status: Active
- Triac Type: Alternistor - Snubberless
- Voltage - Off State: 800V
- Current - On State (It (RMS)) (Max): 16A
- Voltage - Gate Trigger (Vgt) (Max): 1.3V
- Current - Non Rep. Surge 50, 60Hz (Itsm): 160A, 168A
- Current - Gate Trigger (Igt) (Max): 35mA
- Current - Hold (Ih) (Max): 35mA
- Configuration: Single
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: BTA16
