دیتاشیت UC1879, UC2879, UC3879

UC1879, UC2879, UC3879

مشخصات دیتاشیت

نام دیتاشیت UC1879, UC2879, UC3879
حجم فایل 1219.706 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

UC1879, UC2879, UC3879

دانلود دیتاشیت

سایر مستندات

UC3879DW 18 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Management Specialized - PMIC
  • Datasheet: Texas Instruments UC2879DW
  • Package: SOP-20-300mil
  • Manufacturer: Texas Instruments
  • Duty Cycle: 50%
  • Output Isolation: Non-Isolated
  • Topology: Full-Bridge
  • Frequency - Switching: 300kHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Package / Case: 20-SOIC (0.295", 7.50mm Width)
  • Packaging: Tube
  • Internal Switch(s): -
  • Fault Protection: Current Limiting
  • Part Status: Active
  • Voltage - Breakdown: -
  • Series: -
  • Control Features: Frequency Control, Soft Start, Sync
  • Supplier Device Package: 20-SOIC
  • Mounting Type: Surface Mount
  • Base Part Number: UC287
  • Voltage - Supply (Vcc/Vdd): 9.25V ~ 20V
  • detail: Converter Offline Full-Bridge Topology 300kHz 20-SOIC
