دیتاشیت UC3843BD1013TR
مشخصات دیتاشیت
| نام دیتاشیت | UC2842B-45B, UC3842B-45B |
|---|---|
| حجم فایل | 239.299 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت UC2842B-45B, UC3842B-45B |
UC2842B-45B, UC3842B-45B Datasheet |
|---|
مشخصات
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Type: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Boost, Flyback
- Number of Outputs: 1
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 7.6V ~ 30V
- Frequency - Switching: Up to 500kHz
- Duty Cycle (Max): 96%
- Synchronous Rectifier: No
- Clock Sync: No
- Serial Interfaces: -
- Control Features: Frequency Control
- Operating Temperature: 0°C ~ 70°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SO
- Base Part Number: UC3843
- detail: Boost, Flyback Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SO
