دیتاشیت CC2520RHDT

CC2520

مشخصات دیتاشیت

نام دیتاشیت CC2520
حجم فایل 2762.589 کیلوبایت
نوع فایل pdf
تعداد صفحات 135

دانلود دیتاشیت CC2520

CC2520 Datasheet

مشخصات

  • RoHS: true
  • Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
  • Data Rate: 250Kbps
  • Datasheet: Texas Instruments CC2520RHDT
  • Interface: SPI
  • Applications: 802.15.4
  • Frequency Range: 2.4GHz
  • Receive Current: 18.5mA
  • Operating Voltage: 1.8V~3.8V
  • Operating Temperature: -40°C~+125°C
  • Current Of Transmitting: 25.8mA
  • Package: QFN-28-EP(5x5)
  • Manufacturer: Texas Instruments
  • Current - Transmitting: 25.8mA ~ 33.6mA
  • Voltage - Supply: 1.8V ~ 3.8V
  • Data Rate (Max): 250kbps
  • Packaging: Cut Tape (CT)
  • Type: TxRx + MCU
  • Sensitivity: -98dBm
  • GPIO: 6
  • Part Status: Active
  • Protocol: Zigbee®
  • Supplier Device Package: 28-VQFN (5x5)
  • Modulation: DSSS, O-QPSK
  • RF Family/Standard: 802.15.4
  • Frequency: 2.4GHz
  • Serial Interfaces: SPI
  • Current - Receiving: 18.5mA ~ 22.3mA
  • Package / Case: 28-VFQFN Exposed Pad
  • Power - Output: 5dBm
  • Mounting Type: Surface Mount
  • Memory Size: 768B RAM
  • Base Part Number: CC2520
  • Series: -
  • detail: IC RF TxRx + MCU 802.15.4 Zigbee® 2.4GHz 28-VFQFN Exposed Pad
