دیتاشیت DAC7800KU

DAC7800-02

مشخصات دیتاشیت

نام دیتاشیت DAC7800-02
حجم فایل 1657.848 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت DAC7800-02

DAC7800-02 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Texas Instruments DAC7800KU
  • Interface: SPI
  • resolution: 12
  • output type: Current-非缓冲
  • built-up time: 800ns
  • Supply Voltage: 5V
  • Integral nonlinearity: ±1LSB
  • Operating Temperature: -40°C~+85°C
  • Package: SOIC-16-300mil
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Architecture: Multiplying DAC
  • INL/DNL (LSB): ±1 (Max), ±1 (Max)
  • Settling Time: 800ns
  • Number of Bits: 12
  • Part Status: Active
  • Package / Case: 16-SOIC (0.295", 7.50mm Width)
  • Voltage - Supply, Digital: 5V
  • Packaging: Tube
  • Data Interface: SPI
  • Reference Type: External
  • Series: -
  • Differential Output: No
  • Supplier Device Package: 16-SOIC
  • Number of D/A Converters: 2
  • Voltage - Supply, Analog: 5V
  • Base Part Number: DAC7800
  • detail: 12 Bit Digital to Analog Converter 2 16-SOIC
