دیتاشیت L9930PD

L9930

مشخصات دیتاشیت

نام دیتاشیت L9930
حجم فایل 318.797 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت L9930

L9930 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (4)
  • Interface: Parallel
  • Technology: Power MOSFET
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 2A
  • Voltage - Supply: 8V ~ 18V
  • Voltage - Load: 8V ~ 18V
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 20-PowerSOIC (0.433", 11.00mm Width)
  • Supplier Device Package: PowerSO-20
  • Base Part Number: L9930
  • detail: Motor Driver Power MOSFET Parallel PowerSO-20
