MP23AB02BTR دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MP23AB02 Datasheet	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Obsolete
Type: MEMS (Silicon)
Output Type: Analog
Direction: Omnidirectional
Frequency Range: 20Hz ~ 20kHz
Sensitivity: -38dB ±3dB @ 94dB SPL
S/N Ratio: 64dB
Voltage - Rated: 1.8V
Voltage Range: 1.6V ~ 3.6V
Current - Supply: 220µA
Port Location: Bottom
Termination: Solder Pads
Size / Dimension: 0.132" L x 0.098" W (3.35mm x 2.50mm)
Height (Max): 0.043" (1.08mm)
Shape: Rectangular
Base Part Number: MP23
detail: 20Hz ~ 20kHz Analog Microphone MEMS (Silicon) 1.6V ~ 3.6V Omnidirectional (-38dB ±3dB @ 94dB SPL) Solder Pads
