دیتاشیت MP33AB01HTR

مشخصات دیتاشیت

دانلود دیتاشیت MP33AB01H	MP33AB01H Datasheet

Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Obsolete
Type: MEMS (Silicon)
Output Type: Analog
Direction: Omnidirectional
Frequency Range: 100Hz ~ 10kHz
Sensitivity: -38dB ±3dB @ 94dB SPL
S/N Ratio: 66dB
Voltage - Rated: 2.2V
Voltage Range: 1.5V ~ 3.6V
Current - Supply: 250µA
Port Location: Bottom
Termination: Solder Pads
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Height (Max): 0.043" (1.10mm)
Shape: Rectangular
Base Part Number: MP33
detail: 100Hz ~ 10kHz Analog Microphone MEMS (Silicon) 1.5V ~ 3.6V Omnidirectional (-38dB ±3dB @ 94dB SPL) Solder Pads
