دیتاشیت UCC1895/2895/3895

UCC1895/2895/3895

مشخصات دیتاشیت

نام دیتاشیت UCC1895/2895/3895
حجم فایل 2900.305 کیلوبایت
نوع فایل pdf
تعداد صفحات 59

UCC1895/2895/3895

دانلود دیتاشیت

سایر مستندات

UCC3895N 61 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Full-Bridge
  • Datasheet: Texas Instruments UCC2895N
  • Duty Cycle: 100%
  • Supply Voltage: 10V~16.5V
  • Switching Frequency: 1MHz
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Package: DIP-20
  • Manufacturer: Texas Instruments
  • Base Part Number: UCC289
  • Mounting Type: Through Hole
  • Series: -
  • Internal Switch(s): No
  • Supplier Device Package: 20-PDIP
  • Voltage - Breakdown: -
  • Voltage - Start Up: 11V
  • Output Isolation: Isolated
  • Packaging: Tube
  • Package / Case: 20-DIP (0.300", 7.62mm)
  • Control Features: Frequency Control, Soft Start, Sync
  • Voltage - Supply (Vcc/Vdd): 10V ~ 16.5V
  • Frequency - Switching: 1MHz
  • Part Status: Active
  • Fault Protection: -
  • detail: Converter Offline Full-Bridge Topology 1MHz 20-PDIP
