دیتاشیت UC2708DW

UC1708, 2708, 3708

مشخصات دیتاشیت

نام دیتاشیت UC1708, 2708, 3708
حجم فایل 1670.699 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت UC1708, 2708, 3708

UC1708, 2708, 3708 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Texas Instruments UC2708DW
  • Fall Time: 25ns
  • Load Type: MOSFET
  • Rise Time: 25ns
  • Supply Voltage: 5V~35V
  • Number of Drivers: 2
  • Driven Configuration: Low Side
  • Operating Temperature: -25°C~+85°C@(Ta)
  • Peak Output Current(sink): 3A
  • Peak Output Current(source): 3A
  • Package: SOIC-16-300mil
  • Manufacturer: Texas Instruments
  • Voltage - Supply: 5V ~ 35V
  • Current - Peak Output (Source, Sink): 3A, 3A
  • Input Type: Non-Inverting
  • Rise / Fall Time (Typ): 25ns, 25ns
  • Series: -
  • Base Part Number: UC270
  • Supplier Device Package: 16-SOIC
  • Channel Type: Independent
  • Mounting Type: Surface Mount
  • Gate Type: N-Channel, P-Channel MOSFET
  • Logic Voltage - VIL, VIH: 0.8V, 2V
  • Package / Case: 16-SOIC (0.295", 7.50mm Width)
  • Packaging: Tube
  • Part Status: Active
