دیتاشیت SN74S139AN
مشخصات دیتاشیت
| نام دیتاشیت | SN54/74(LS,S)139/A |
|---|---|
| حجم فایل | 1200.218 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 18 |
دانلود دیتاشیت SN54/74(LS,S)139/A |
SN54/74(LS,S)139/A Datasheet |
|---|
مشخصات
- RoHS: true
- Type: Decoder/Demultiplexers
- Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
- Datasheet: Texas Instruments SN74S139AN
- Sink Current: 8mA
- Source Current: 400uA
- Supply Voltage: 4.75V~5.25V
- Operating temperature: 0°C~+70°C
- Voltage Supply Source: Single supply
- Package: PDIP-16
- Manufacturer: Texas Instruments
- Voltage - Supply: 4.75V ~ 5.25V
- Base Part Number: SN74S1
- Circuit: 1 x 2:4
- Series: 74S
- Current - Output High, Low: 400µA, 8mA
- Independent Circuits: 2
- Mounting Type: Through Hole
- Supplier Device Package: 16-PDIP
- Package / Case: 16-DIP (0.300", 7.62mm)
- Packaging: Tube
- Part Status: Active
- detail: Decoder/Demultiplexer 1 x 2:4 16-PDIP
