دیتاشیت SN74AS11N

SN54/74(ALS,AS)11(A)

مشخصات دیتاشیت

نام دیتاشیت SN54/74(ALS,AS)11(A)
حجم فایل 1195.681 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت SN54/74(ALS,AS)11(A)

SN54/74(ALS,AS)11(A) Datasheet

مشخصات

  • Series: 74AS
  • Current - Quiescent (Max): 7mA
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Logic Level - High: 2V
  • Number of Circuits: 3
  • Number of Inputs: 3
  • Features: -
  • Current - Output High, Low: 2mA, 20mA
  • Mounting Type: Through Hole
  • Supplier Device Package: 14-PDIP
  • Logic Type: AND Gate
  • Operating Temperature: 0°C ~ 70°C
  • Max Propagation Delay @ V, Max CL: 6ns @ 5V, 50pF
  • Manufacturer: Texas Instruments
  • Voltage - Supply: 4.5V ~ 5.5V
  • Packaging: Tube
  • Base Part Number: SN74AS1
  • Part Status: Active
  • Logic Level - Low: 0.8V
  • detail: AND Gate IC 3 Channel 14-PDIP
