دیتاشیت AT91SAM9G20B-CU
مشخصات دیتاشیت
| نام دیتاشیت |
SAM9G20
|
| حجم فایل |
2773.6
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
798
|
مشخصات
-
RoHS:
true
-
EEPROM:
-
-
CPU Core:
ARMOther series
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
RAM Size:
-
-
Watchdog:
-
-
ADC (Bit):
-
-
DAC (Bit):
-
-
Datasheet:
Microchip Tech AT91SAM9G20B-CU
-
PWM (Bit):
-
-
Real-Time Clock:
-
-
CPU Maximum Speed:
400MHz
-
GPIO Ports Number:
-
-
Low-Voltage Detect:
-
-
CCP Capture/Compare:
-
-
Internal Comparator:
-
-
Internal Oscillator:
-
-
Program Memory Type:
-
-
Direct Memory Access:
-
-
Program Storage Size:
-
-
Universal Serial Bus:
Yes
-
communication protocol:
-
-
Operating Voltage Range:
-
-
Infrared Data Association:
-
-
Operating Temperature Range:
-40°C~+85°C
-
Secure Digital Input and Output:
-
-
Package:
LFBGA-217
-
Manufacturer:
Microchip Tech
-
Series:
SAM9G
-
Packaging:
Tray
-
Part Status:
Active
-
Core Processor:
ARM926EJ-S
-
Number of Cores/Bus Width:
1 Core, 32-Bit
-
Speed:
400MHz
-
Co-Processors/DSP:
-
-
RAM Controllers:
SDRAM, SRAM
-
Graphics Acceleration:
No
-
Display & Interface Controllers:
-
-
Ethernet:
10/100Mbps
-
SATA:
-
-
USB:
USB 2.0 (2)
-
Voltage - I/O:
1.8V, 3.3V
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Security Features:
-
-
Package / Case:
217-LFBGA
-
Supplier Device Package:
217-LFBGA (15x15)
-
Additional Interfaces:
EBI/EMI, I²C, MMC/SD/SDIO, SPI, SSC, UART/USART
-
Base Part Number:
AT91SAM9G20
-
detail:
ARM926EJ-S Microprocessor IC SAM9G 1 Core, 32-Bit 400MHz 217-LFBGA (15x15)
