دیتاشیت SN74LS27NSR

SN54/74(LS)27

مشخصات دیتاشیت

نام دیتاشیت SN54/74(LS)27
حجم فایل 1048.73 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت SN54/74(LS)27

SN54/74(LS)27 Datasheet

مشخصات

  • RoHS: true
  • Category: Logic ICs/Gates
  • Datasheet: Texas Instruments SN74LS27NSR
  • Package: SOP-14-208mil
  • Manufacturer: Texas Instruments
  • Series: 74LS
  • Current - Quiescent (Max): 4mA
  • Package / Case: 14-SOIC (0.209", 5.30mm Width)
  • Logic Level - High: 2V
  • Number of Circuits: 3
  • Number of Inputs: 3
  • Features: -
  • Current - Output High, Low: 400µA, 8mA
  • Mounting Type: Surface Mount
  • Supplier Device Package: 14-SOP
  • Logic Type: NOR Gate
  • Operating Temperature: 0°C ~ 70°C
  • Max Propagation Delay @ V, Max CL: 15ns @ 5V, 15pF
  • Voltage - Supply: 4.75V ~ 5.25V
  • Packaging: Cut Tape (CT)
  • Base Part Number: SN74LS27
  • Part Status: Active
  • Logic Level - Low: 0.8V
  • detail: NOR Gate IC 3 Channel 14-SOP
