دیتاشیت ADM7172ACPZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADM7172
|
| حجم فایل |
1109.225
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
23
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Analog Devices ADM7172ACPZ-R7
-
Output Type:
Adjustable
-
Output Current:
2A
-
Output Voltage:
1.2V~6.23V
-
Dropout Voltage:
27V@(2A)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
6.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
2mA
-
Power Supply Rejection Ratio (PSRR):
60dB@(100kHz),20dB@(1MHz)
-
Package:
LFCSP-8
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
6.5V
-
Voltage - Output (Min/Fixed):
1.2V
-
Voltage - Output (Max):
6.23V
-
Voltage Dropout (Max):
.27V @ 2A
-
Current - Output:
2A
-
Current - Quiescent (Iq):
2mA
-
Current - Supply (Max):
8.7mA
-
PSRR:
60db ~ 20dB (100kHz ~ 1MHz)
-
Control Features:
Enable, Soft Start
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
8-WFDFN Exposed Pad, CSP
-
Supplier Device Package:
8-LFCSP-WD (3x3)
-
Base Part Number:
ADM7172
-
detail:
Linear Voltage Regulator IC 1 Output 2A 8-LFCSP-WD (3x3)
