دیتاشیت AD5754BREZ
مشخصات دیتاشیت
| نام دیتاشیت |
AD5724,34,54
|
| حجم فایل |
1310.404
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
31
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
-
Datasheet:
Analog Devices AD5754BREZ
-
Interface:
SPI;DSP
-
Resolution:
16Bit
-
Output Type:
Voltage-缓冲
-
Settling Time:
12us
-
Supply Voltage:
2.7V~5.5V
-
Integral nonlinearity:
±16LSB;±1LSB
-
Operating Temperature:
-40°C~+85°C
-
Package:
TSSOP-24-EP
-
Manufacturer:
Analog Devices
-
Series:
iCMOS®
-
Packaging:
Tube
-
Part Status:
Active
-
Number of Bits:
16
-
Number of D/A Converters:
4
-
Differential Output:
No
-
Data Interface:
SPI, DSP
-
Reference Type:
External
-
Voltage - Supply, Analog:
±4.5V ~ 16.5V
-
Voltage - Supply, Digital:
2.7V ~ 5.5V
-
INL/DNL (LSB):
±16 (Max), ±1 (Max)
-
Architecture:
String DAC
-
Package / Case:
24-TSSOP (0.173", 4.40mm Width) Exposed Pad
-
Supplier Device Package:
24-TSSOP-EP
-
Mounting Type:
Surface Mount
-
Base Part Number:
AD5754
-
detail:
16 Bit Digital to Analog Converter 4 24-TSSOP-EP
