دیتاشیت AD8001ANZ

AD8001

مشخصات دیتاشیت

نام دیتاشیت AD8001
حجم فایل 304.586 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت AD8001

AD8001 Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Analog Devices AD8001ANZ
  • -3db Bandwidth: 880MHz
  • Output Current: 70mA
  • Number of Circuits: 1
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 5uA
  • Gain Bandwidth Product(GBP): -
  • Package: PDIP-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Amplifier Type: Current Feedback
  • Output Type: -
  • Slew Rate: 1200V/µs
  • Current - Input Bias: 5µA
  • Voltage - Input Offset: 2mV
  • Current - Supply: 5mA
  • Current - Output / Channel: 70mA
  • Voltage - Supply, Single/Dual (±): ±3V ~ 6V
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: AD8001
  • detail: Current Feedback Amplifier 1 Circuit 8-PDIP
