دیتاشیت ADF7242BCPZ

ADF7242

مشخصات دیتاشیت

نام دیتاشیت ADF7242
حجم فایل 1278.054 کیلوبایت
نوع فایل pdf
تعداد صفحات 108

دانلود دیتاشیت ADF7242

ADF7242 Datasheet

مشخصات

  • RoHS: true
  • Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
  • Datasheet: Analog Devices ADF7242BCPZ
  • Package: LFCSP-32-EP(5x5)
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tray
  • Part Status: Active
  • Type: TxRx + MCU
  • RF Family/Standard: 802.15.4
  • Protocol: -
  • Modulation: DSSS, GSK, GFSK, GMSK, MSK, O-QPSK
  • Frequency: 2.4GHz
  • Data Rate (Max): 2Mbps
  • Power - Output: 4.8dBm
  • Sensitivity: -96dBm
  • Memory Size: 4kB ROM, 2.5kB RAM
  • Serial Interfaces: SPI
  • GPIO: 7
  • Voltage - Supply: 1.8V ~ 3.6V
  • Current - Receiving: 19mA
  • Current - Transmitting: 16.5mA ~ 25mA
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 32-WFQFN Exposed Pad, CSP
  • Supplier Device Package: 32-LFCSP-WQ (5x5)
  • Base Part Number: ADF7242
  • detail: IC RF TxRx + MCU 802.15.4 2.4GHz 32-WFQFN Exposed Pad, CSP
