دیتاشیت SN74ALS621A-1N
مشخصات دیتاشیت
نام دیتاشیت | SN74ALS620A/21A/23A, SN74AS623 |
---|---|
حجم فایل | 1229.692 کیلوبایت |
نوع فایل | |
تعداد صفحات | 19 |
دانلود دیتاشیت SN74ALS620A/21A/23A, SN74AS623 |
SN74ALS620A/21A/23A, SN74AS623 Datasheet |
---|
مشخصات
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74ALS621A-1N
- Input type: -
- output type: Open Collector
- Logic Family: 74ALS
- Sink Current: 24mA
- Source Current: -
- Supply Voltage: 4.5V~5.5V
- Number of Channels: 8
- Operating Temperature: 0°C~+70°C
- Package: PDIP-20
- Manufacturer: Texas Instruments
- Series: 74ALS
- Package / Case: 20-DIP (0.300", 7.62mm)
- Number of Bits per Element: 8
- Number of Elements: 1
- Supplier Device Package: 20-PDIP
- Part Status: Active
- Current - Output High, Low: -, 24mA
- Mounting Type: Through Hole
- Base Part Number: SN74ALS6
- Voltage - Supply: 4.5V ~ 5.5V
- Packaging: Tube
- Logic Type: Transceiver, Non-Inverting
- detail: Transceiver, Non-Inverting 1 Element 8 Bit per Element Open Collector Output 20-PDIP
