- دیتاشیت ADG5208FBRUZ
ADG5208FBRUZ دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADG5208FBRUZ |
|---|---|
| حجم فایل | 101.534 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت ADG5208FBRUZ |
دانلود دیتاشیت |
|---|
سایر مستندات
ADG5208F, 9F Series Datasheet 27 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices ADG5208FBRUZ
- Turn-on time: 170ns
- Turn-off time: 140ns
- Supply Voltage: 9V~40V
- Number of Channels: 1
- On-State Resistance (Max): 160Ω
- Package: TSSOP-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Switch Circuit: -
- Multiplexer/Demultiplexer Circuit: 8:1
- Number of Circuits: 1
- Channel-to-Channel Matching (ΔRon): 3.5Ohm
- Voltage - Supply, Single (V+): 9V ~ 40V
- Voltage - Supply, Dual (V±): ±9V ~ 22V
- Switch Time (Ton, Toff) (Max): 170ns, 140ns
- -3db Bandwidth: 60MHz
- Charge Injection: 0.3pC
- Channel Capacitance (CS(off), CD(off)): 2.8pF, 33pF
- Current - Leakage (IS(off)) (Max): 100pA
- Crosstalk: -90dB @ 1MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
- Base Part Number: ADG5208
- detail: 1 Circuit IC Switch 8:1 160Ohm 16-TSSOP
