دیتاشیت OPA2604AP
مشخصات دیتاشیت
| نام دیتاشیت | Signal e-Book: OP Amp Design Topics |
|---|---|
| حجم فایل | 17975.467 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 37 |
دانلود دیتاشیت Signal e-Book: OP Amp Design Topics |
Signal e-Book: OP Amp Design Topics Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/FET InputAmplifiers
- Datasheet: Texas Instruments OPA2604AP
- Number of Circuits: 2
- Operating Temperature: -40°C~+85°C
- Supply Current Per Channel: 10.5mA
- Gain Bandwidth Product(GBP): 20MHz
- Package: DIP-8
- Manufacturer: Texas Instruments
- Series: -
- Package / Case: 8-DIP (0.300", 7.62mm)
- Current - Supply: 10.5mA
- Voltage - Input Offset: 1mV
- Mounting Type: Through Hole
- Part Status: Obsolete
- Slew Rate: 25V/µs
- Voltage - Supply, Single/Dual (±): 9V ~ 48V, ±4.5V ~ 24V
- Gain Bandwidth Product: 20MHz
- Amplifier Type: General Purpose
- Current - Output / Channel: 35mA
- Packaging: Tube
- Base Part Number: OPA260
- Current - Input Bias: 100pA
- Output Type: -
- Supplier Device Package: 8-PDIP
- detail: General Purpose Amplifier 2 Circuit 8-PDIP
