دیتاشیت AD5314BRM
مشخصات دیتاشیت
| نام دیتاشیت | AD5304,14,24 Datasheet |
|---|---|
| حجم فایل | 610.167 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت AD5304,14,24 Datasheet |
AD5304,14,24 Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Number of Bits: 10
- Number of D/A Converters: 4
- Settling Time: 9µs
- Output Type: Voltage - Buffered
- Differential Output: No
- Data Interface: SPI, DSP
- Reference Type: External
- Voltage - Supply, Analog: 2.5V ~ 5.5V
- Voltage - Supply, Digital: 2.5V ~ 5.5V
- INL/DNL (LSB): ±0.5, ±0.05
- Architecture: String DAC
- Operating Temperature: -40°C ~ 105°C
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 10-MSOP
- Mounting Type: Surface Mount
- Base Part Number: AD5314
- detail: 10 Bit Digital to Analog Converter 4 10-MSOP
