ADG211AKN 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Switch Circuit: SPST - NC
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 4
- On-State Resistance (Max): 115Ohm
- Channel-to-Channel Matching (ΔRon): 5.75Ohm
- Voltage - Supply, Single (V+): 15V
- Voltage - Supply, Dual (V±): ±15V
- Switch Time (Ton, Toff) (Max): 600ns, 450ns
- -3db Bandwidth: -
- Charge Injection: 20pC
- Channel Capacitance (CS(off), CD(off)): 5pF, 5pF
- Current - Leakage (IS(off)) (Max): 5nA
- Crosstalk: -80dB @ 100kHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Through Hole
- Package / Case: 16-DIP (0.300", 7.62mm)
- Supplier Device Package: 16-PDIP
- Base Part Number: ADG211
- detail: 4 Circuit IC Switch 1:1 115Ohm 16-PDIP
