AD817AN Datasheet

AD817

Datasheet specifications

Datasheet's name AD817
File size 225.943 KB
File type pdf
Number of pages 12

Download Datasheet AD817

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Amplifier Type: General Purpose
  • Number of Circuits: 1
  • Output Type: -
  • Slew Rate: 350V/µs
  • Gain Bandwidth Product: 50MHz
  • -3db Bandwidth: 50MHz
  • Current - Input Bias: 3.3µA
  • Voltage - Input Offset: 500µV
  • Current - Supply: 7mA
  • Current - Output / Channel: 50mA
  • Voltage - Supply, Single/Dual (±): 5V ~ 36V, ±2.5V ~ 18V
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: AD817
