دیتاشیت SN74LS173ANSR

مشخصات دیتاشیت

دانلود دیتاشیت SN54/74173, SN54/74(LS,S)173	SN54/74173, SN54/74(LS,S)173 Datasheet

Series: 74LS
Type: D-Type
Package / Case: 16-SOIC (0.209", 5.30mm Width)
Current - Output High, Low: 2.6mA, 24mA
Number of Elements: 1
Function: Master Reset
Clock Frequency: 50MHz
Current - Quiescent (Iq): 24mA
Part Status: Obsolete
Number of Bits per Element: 4
Mounting Type: Surface Mount
Operating Temperature: 0°C ~ 70°C (TA)
Max Propagation Delay @ V, Max CL: 25ns @ 5V, 45pF
Manufacturer: Texas Instruments
Voltage - Supply: 4.75V ~ 5.25V
Packaging: Tape & Reel (TR)
Base Part Number: SN74LS17
Supplier Device Package: 16-SO
Output Type: Tri-State, Non-Inverted
Trigger Type: Positive Edge
detail: Flip Flop 1 Element D-Type 4 Bit Positive Edge 16-SOIC (0.209", 5.30mm Width)
