AT86RF212B-ZUR 数据手册
其他文档
AT86RF212B Complete 212 pages
技术规格
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 1Mbps
- Datasheet: Microchip Tech AT86RF212B-ZUR
- Interface: SPI
- Applications: 802.15.4,General-purpose ISM<1GHz
- Frequency Range: 769MHz~935MHz
- Receive Current: 8.7mA
- Operating Voltage: 1.8V~3.6V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 9.5mA
- Package: QFN-32(5x5)
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: TxRx + MCU
- RF Family/Standard: 802.15.4, General ISM < 1GHz
- Protocol: 6LoWPAN, Zigbee®
- Modulation: BPSK, O-QPSK
- Frequency: 769MHz ~ 935MHz
- Data Rate (Max): 1Mbps
- Power - Output: 10dBm
- Sensitivity: -110dBm
- Memory Size: 128B SRAM
- Serial Interfaces: SPI
- Voltage - Supply: 1.8V ~ 3.6V
- Current - Receiving: 8.7mA ~ 9.2mA
- Current - Transmitting: 9.5mA ~ 26.5mA
- Mounting Type: Surface Mount
- Package / Case: 32-VFQFN Exposed Pad
- Supplier Device Package: 32-QFN (5x5)
- Base Part Number: AT86RF212B
- detail: IC RF TxRx + MCU 802.15.4, General ISM < 1GHz 6LoWPAN, Zigbee® 769MHz ~ 935MHz 32-VFQFN Exposed Pad
