دیتاشیت NRF51422-QFAA-R
مشخصات دیتاشیت
| نام دیتاشیت | nRF51422 Specification |
|---|---|
| حجم فایل | 7393.559 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 115 |
دانلود دیتاشیت nRF51422 Specification |
nRF51422 Specification Datasheet |
|---|
مشخصات
- I2C: 1
- SPI: 1
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M0
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 16KB
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: Nordic Semicon NRF51422-QFAA-R
- PWM (Bit): -
- UART/USART: 1
- 16Bit Timer: 2
- 32Bit Timer: 1
- Real-Time Clock: Yes
- CPU Maximum Speed: -
- GPIO Ports Number: 31
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: Yes
- Internal Oscillator: Yes
- Peripheral/Function: Hardware Cryptographic Engine;Real-Time Clock;WDT;On-chip temperature sensor;Bluetooth protocol stack
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 256KB
- Universal Serial Bus: -
- communication protocol: 蓝牙协议
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -25°C~+75°C
- Secure Digital Input and Output: -
- Package: QFN-48-EP(6x6)
- Manufacturer: Nordic Semicon
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Type: TxRx + MCU
- RF Family/Standard: Bluetooth, General ISM > 1GHz
- Protocol: ANT, Bluetooth v4.0
- Modulation: GFSK
- Frequency: 2.4GHz
- Data Rate (Max): 2Mbps
- Power - Output: 4dBm
- Sensitivity: -96dBm
- Memory Size: 256kB Flash, 16kB RAM
- Serial Interfaces: I²C, SPI, UART
- GPIO: 32
- Voltage - Supply: 1.8V ~ 3.6V
- Current - Receiving: 12.6mA ~ 13.4mA
- Current - Transmitting: 5.5mA ~ 16mA
- Operating Temperature: -25°C ~ 75°C
- Mounting Type: Surface Mount
- Package / Case: 48-VFQFN Exposed Pad
- Supplier Device Package: 48-QFN (6x6)
- detail: IC RF TxRx + MCU Bluetooth, General ISM > 1GHz ANT, Bluetooth v4.0 2.4GHz 48-VFQFN Exposed Pad
