دیتاشیت FAN4174IS5X
مشخصات دیتاشیت
| نام دیتاشیت | FAN4174/FAN4274 |
|---|---|
| حجم فایل | 1214.737 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت FAN4174/FAN4274 |
FAN4174/FAN4274 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: onsemi FAN4174IS5X
- Rail to Rail: 轨到轨
- -3db Bandwidth: 3.7MHz
- Output Current: 33mA
- Number of Circuits: 1
- Operating Temperature: -40°C~+85°C
- Current - Input Bias(Ib): 5pA
- Gain Bandwidth Product(GBP): 3.7MHz
- Package: SOT-23-5
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Amplifier Type: Voltage Feedback
- Output Type: Rail-to-Rail
- Slew Rate: 3V/µs
- Gain Bandwidth Product: 3.7MHz
- Current - Input Bias: 5pA
- Voltage - Input Offset: 8mV
- Current - Supply: 200µA
- Current - Output / Channel: 33mA
- Voltage - Supply, Single/Dual (±): 2.3V ~ 5.25V
- Mounting Type: Surface Mount
- Package / Case: SC-74A, SOT-753
- Supplier Device Package: SOT-23-5
- Base Part Number: FAN4174
